Deublin product line: SRT
Slip Rings - Through Bore

Deublin product line: SRT

Slip Rings - Through Bore

	SRT-25	SRT-38	SRT-50
Type	Through Bore	Through Bore	Through Bore
Inner Diameter	25,4mm / 1 inch	38,1mm / 1-1/2 inch	50,8 / 2 inches
Signal Current	5A	5A	5A
Max number of channels signal	48	48	72
Power Current	10A	10A	10A
Max number of channels Power	36	36	48
Housing Material	Plastic	Plastic	Plastic
Cover Material	Aluminum	Aluminum	Aluminum
Conductor Ring Material	Silver/Gold plated	Silver/Gold plated	Silver/Gold plated
Lead length	300mm	300mm	300mm
Protection class	IP51-68	IP51-68	IP51-68
Max rotational speed	250/1000 RPM	250/1000 RPM	250/1000 RPM
Mounting position	Vertical/Horizontal	Vertical/Horizontal	Vertical/Horizontal
Working temperature	-30°C/80°C	-30°C/80°C	-30°C/80°C
Operating Humidity	0-85% RH	0-85% RH	0-85% RH
Rotation sense	CW/CCW	CW/CCW	CW/CCW
Rated Voltage	0-240/440/690VAC/DC	0-240/440/690VAC/DC	0-240/440/690VAC/DC
Self Diagnosis PCB	yes	yes	yes
Polyfilament brushes/Data channels	yes	yes	yes
Graphite brushes	no	no	no
Insulation resistance	>1000 Mohm/500VDC	>1000 Mohm/500VDC	>1000 Mohm/500VDC
Insulation strength	>1000VAC @ 50Hz 60 sec	>1000VAC @ 50Hz 60 sec	>1000VAC @ 50Hz 60 sec
Electrical Noise	< 10 mOhm	< 10 mOhm	< 10 mOhm
Cable wire	AWG18-20	AWG18-20	AWG18-20
Torque	Approx 0,1Nm	Approx 0,1Nm	Approx 0,1Nm

Schleifring-Datenbl?tter

SlipRing_SRT25_EU_DE_Rev4.pdf
(159.9 KiB)

SlipRing_SRT38_EU_DE_Rev4.pdf
(125.3 KiB)

SlipRing_SRT50_EU_DE_Rev4.pdf
(125.1 KiB)
